Saturday 28 April 2018

EXP2- 5 real time image captures showing a lumion environment and 3 texture images

Site view of station

Exterior view of station

Interior view of station

Entry view

View under the bridge

Texture 1

Using the combination of lines and shadow blocks to create a coherent visual pattern that reflects the

extended aesthetics of parallelism.

Texture 2

A thread-like sense of rotation is created by using the texture of curve lines to reflect the organic growth.

Texture 3

Extended texture placed on the roof connects with the reflection of light with the glass material to reflect a dynamic collision visual impact, which shows strong vitality.

EXP2- two concepts

1. Horizontal

Le Corbusier is good at using the horizontal spaces to create a synthetic shape to emphase the outside view. Horizontal lines are easy to help to locate the position of station within city.

2. Organic

By using advanced technology, servo-stockholm well integrates the natural environment with the system of architecture. The organic glass shape of shell can use solar energy to provide electricity of the station.
